High Power double Reussen shielded 3x5.50mm² (85055) Mains power Cables
605.000,00 ₫
SKU
85055
Double Reussen shieded power cable for mains power to your Hi-End Audio Gear. This cable ensures best transport of needed energy (up to 4000 Watt and 33 Ampere current) to our device but due to our exklusive Double Reussen shielding and conductive copper layer (K6160), this is protecting your signal cables nearby even better from humm and RF noise generated by the 50/60Hz signal going tru the power supply cable.
Harmonisierter Produktecode: 2YSL(ST)DY3G5.5
Construction: |
||
| 1 = Jacket: | PVC (YM2) 1.30mm. 13.50mm Ø dark blue RAL5013 | |
| 2 = Shield 1: | Bare copper wires (0.20 mm) 100% coverage S | |
| 3 = Shield 2 | Bare copper wires (0.20 mm) 100% coverage Z | |
| 4 = Shield # 3 | K6160 Polyester nonwoven thermally bonded, both sides copper coated, counter wrapped to the twisted conductors. | |
| 5 = Insulation 3x: | PE-2YI 1 0.80mm thickness. Nominal Diameter 4.60 mm, Color code: Blue-Brown-Yellow/Green |
|
| 6 = Conductor 3x: | 105x0,25mm Ø bare OFC copper wires 2,97mm Ø = 5,50mm² |
|
Technical datas: |
||
| Conductor resistance: | < 3.50 Ohm/km | |
| Rating Voltage: |
300/500V |
|
| Test Voltage: | 2000 Veff | |
| Temperature range: | -30° to +70° C | |
| Maximum Watts load: | @ current 33 Ampere/Line | < 4000 Watt |
