10561 GAC-2 UltraPro each conductor shielded cable Hi-End Microphone Cable
Còn hàng
Vận chuyển hôm nay nếu đặt hàng trong 9 giờ và 26 phút!
Balanced 5 times shielded audio cable! Ultraflexible professional audio cable for microphones. 'Double Reussen shield', velvet matte non-light reflecting PVC-jacket material.
A unique construction invented by Gotham Audio design.
Each conductor is shielded with a lap shield 100% covering copper wires (7) (Reussen shield) plus a conductive separation layer (6) (Aluminium coated polyester). This conductor is twisted around conductor no 2 and turn is hold in place with another aluminium coated layer, followed by Gotham's unique double Reussen shield. This cable is absolutely uncompromised to achieve maximum shielding possible while the flexibility and durability is still very good and the cable can be used in mobile applications as well.
The cable is built with a stabile 110 ohm impedance and can be used for analog balanced audio signals as well as digital audio signals in the AES-EBU format. Ideal cable for accomodation of XLR-connectors with corresponding 8mm diameter cable claps.
Available as designated AES-EBU cable with purple color (10666), same construction but with purple color.
Construction: | ||
| 1 = Jacket: | PVC, max. Ø 8,00 mm in dark blue RAL5013 (10666 in purple as shown) | |
| 2 = Over all Shield No. 1 | Bare copper wires (0.10 mm) 100% coverage | |
| 3 = Over all Shield No. 2 | Bare copper wires (0.10 mm) 100% coverage | |
| 4 = Layer | Polyester nonwoven thermally bonded, both sides aluminium coated | |
| 5 = Seperation | Filler material viscose | |
| 6 = conductor shield layer | Polyester nonwoven thermally bonded, both sides aluminium coated | |
| 7 = conductor shield | Bare copper wires (0.10 mm) 100% coverage | |
| 8 = Insulation | Cellular PE, Ø 2.00mm white/red | |
| 9 = Conductor | Stranded bare LCOF copper wires 64 x 0.10mm (0.50mm²) 64x38AWG = 20AWG | |
Technical Datas: | ||
| Conductor resistance: | max 39 ohm/km | |
| Shielding resistance: | < 28 Ohm/km | |
| Capacitance: | Conductor/ Cond: | max. 50 nF/km |
| Conductor/Shield: | 135 nF /km | |
| Impedance: | 110 Ohm | |
| Test voltage: | 2000 veff | |
| Temperature range: | flexi-installed: | -5° to +50° C |
| fix-installed: | -30° to +70° C | |
